Alloy Beam 450mm


Compatibility with traditional scaffold structures and temporary roofs. Combine high strength with low weight and cost. Available in 2m, 3m, 4m, 5m, 6m and 8m lengths along with 4.1m, 6.1m and 8.1m. Top and bottom chords of the beams are manufactured in traditional scaffold tube size, allowing easy connection of traditional scaffold couplers. Vertical posts are provided at each end of the beam and at intermediate locations. 450mm                                                                                 beams offer an economical solution for the creation of beams spans, crash                                                                               decks and medium sized temporary roof structures.


DESSA 780mm


Higher load bearing capacities than any other similar beams. Multiple sizes available – 45cm, 75cm and 78cm deep. All members manufactured in traditional scaffold tube size. Vertical posts are provided each 1m on all beam sizes, the only beam to offer consistent node spacing when multiple beams are joined. All node gaps large enough to connect a standard scaffold fitting. Joined using simple alloy spigots and quick release spring clips. UNI ROOF                                                                              components available for all sizes


750mm X-Beams


X-Beams are a lightweight alternative to traditional style scaffolding beams. They possess an unsurpassed weight to strength ratio thanks to their unique frame design that means less beams per job. The X-Beam's quick fit connecting system using spring clips and spigots also means easy assembly, yet another advantage over traditional style scaffolding.



Asterix HD 1.3M


Higher load bearing capacities than any other tubular beam. 8 hole spigot for strength. Available in 0.55,1,2,3,4m lengths from stock. 5&6m lengths available by special order. 18 degree, 12 degree and 6 degree ridge beams available last quarter 2013. All chords and posts manufactured in traditional scaffold tube size. Vertical posts are provided each 1m on all beam sizes. All posts have collar to enable snap on plan brace to be used as part of the DESSA UNI roof                                                                          system – eliminates K frames. Consistent diagonal node spacing when multiple beams are joined. Closed end beams so whole length can be used for support unlike other 750 beams where end support has to be set in 0.5m each side, effectively wasting 1m of beam each time. Joined using simple spigots & quick release spring clips. Suitable for use with DESSA Uni Roof any other existing roof systems.
